The FNIRSI SG-002A Signal Generator is a versatile DDS (Direct Digital Synthesis) function generator designed for a wide range of applications, including electronics testing, signal simulation, waveform generation, and educational purposes. This compact, easy-to-use tool provides a variety of waveform outputs and is ideal for both hobbyists and professionals who require accurate and stable signal generation.

Features:

• Signal Types: Offers multiple waveform options, including Sine, Square, Triangle, Ramp, and Pulse waveforms.
• Frequency Range: Wide frequency range from 1Hz to 1MHz, allowing for testing and simulation across various applications.
• Amplitude Control: Adjustable amplitude, ensuring that signals can be tailored to different voltage levels for various circuit testing.
• Precise Frequency Generation: Based on Direct Digital Synthesis (DDS) technology, which ensures high precision and stability of frequency and waveforms.
• User-Friendly Interface: Simple control panel with a large LCD screen for easy configuration and monitoring of output parameters.
• Portability: Compact and portable design, making it suitable for both lab environments and field use.

Specifications:

• Signal Output Types:
  • Sine Wave
  • Square Wave
  • Triangle Wave
  • Ramp Wave
  • Pulse Wave
• Frequency Range: 1Hz to 1MHz
• Amplitude: Adjustable, typically ranging from 0 to 10Vpp
• Output Impedance: Typically 50Ω
• Duty Cycle: Adjustable for square wave signals
• Resolution: 1Hz for frequency, ensuring precise adjustments
• Waveform Accuracy: High waveform accuracy, ensuring signals are clean and reliable
• Waveform Symmetry: Excellent symmetry for sine and square waves
• Display: LCD screen to display current output parameters (frequency, amplitude, waveform type)
• Modulation: Basic AM (Amplitude Modulation) and FM (Frequency Modulation) capabilities

Applications:

• Electronics Testing: Ideal for testing and troubleshooting electronic circuits, especially in labs and research environments.
• Signal Simulation: Useful for simulating real-world signals for system testing, including communications, audio, and other signal-dependent applications.
• Educational Use: Excellent tool for teaching and learning signal generation, waveform analysis, and circuit testing in schools and universities.
• Prototyping: Suitable for generating various waveforms in the development of new electronic devices and systems.

Package Includes:

• 1 x FNIRSI SG-002A Signal Generator DDS Function Generator
• 1 x Power Adapter
• 1 x BNC to Alligator Clip Cable
•
