Nema 17 Stepper Motor 17HS4023 23mm Length 1.0A High Torque 14N.cm CNC 3D Printer Parts
In stock
Order before 12.00PM
Original Twotrees Brand Nema17 Stepper Motor.
High quality Motor ensures better accuracy, step angle and torque.
Specifically designed for 3D Printers and CNC.
This brand motor has relatively high high-holding torque that gives the user the ability to incrementally “step” to the next position. This results in a simple positioning system that doesn’t require an encoder and makes stepper motor controllers very simple to build and use.
This specific NEMA 17 Stepper Motor offers 14 N.cm of torque and 200 steps per revolution. Additionally, the motor comes with a cable with JST and Dupont connector at each end.
Specifications:
- Brand: Twotrees
- Phase: 2-phase step drive.
- Step angle: 1.8 ± 5% °/Step.
- Voltage: 12V.
- Current: 700 mA/phase.
- Resistance: 4 ± 10% Ω/Phase.
- Inductance: 3.2 ± 20% mH/Phase.
- Holding Torque: 14 N.cm (1.24 lb.in).
- Detent Torque: 2.2 N.cm (0.2 lb.in).
- Rotational Inertia: 54 g.cm² (0.3 oz.in²).
- Insulation Class: B (see table below for temperatures).
- Ambient Temperature Required: -20 to 50°C (-4 to 122°F).
- Pinout: Red = A+.
Green = A.
Black = B+.
Blue = B.
*The two unused pins are “common pins” and are used in uni-polar mode.. - Body Dimensions: 41.8 x 41.8 x 23.8 mm (1.65 x 1.65” x 0.94”).
- Shaft Diameter: 5mm.
- Shaft Length: 21mm.
- Weight: 130g (4.6 oz.)
Pinout:
- Red = A+.
- Green = A.
- Black = B+.
- Blue = B.
