NVIDIA Jetson Orin NX AI Development Kit (16GB)
In stock
Order before 12.00PM
The NVIDIA Jetson Orin NX 16GB is designed for advanced AI workloads, offering unparalleled performance for a wide range of AI applications. With its compact form factor, the Jetson Orin NX provides the compute power required for AI-driven systems like robotics, drones, autonomous machines, and smart cameras. It delivers 100 TOPS of AI performance, enabling developers to implement sophisticated AI models such as object detection, image classification, speech recognition, and more.
Jetson Orin NX runs the NVIDIA AI software stack, which includes frameworks like NVIDIA Isaac for robotics, DeepStream for Vision AI, and Riva for conversational AI. By using tools like NVIDIA Omniverse Replicator and TAO Toolkit, developers can accelerate the creation of AI models and applications, reducing development time. With support for external NVMe storage, multiple camera inputs, and high-speed interfaces, this module is ideal for edge computing and AI workloads requiring real-time processing and inference.
Specifications:
| Version | 8GB | 16GB |
|---|---|---|
| AI performance | 70TOPS | 100TOPS |
| GPU | 1024-core N-VIDIA Ampere architecture GPU with 32 Tensor Cores | |
| GPU Frequency | 765MHz (Max) | 918MHz (Max) |
| CPU | 6-core Arm® Cortex®-A78AE v8.2 64-bit CPU, 1.5MB L2 + 4MB L3 | 8-core Arm® Cortex®-A78AE v8.2 64-bit CPU, 2MB L2 + 4MB L3 |
| CPU Frequency | 2GHz (Max) | |
| DL accelerator | 1x N-VDLA v2 | 2x N-VDLA v2 |
| DLA Frequency | 614MHz (Max) | |
| Vision Accelerator | 1x PVA v2 | |
| Memory | 8GB 128-bit LPDDR5, 102.4GB/s | 16GB 128-bit LPDDR5, 102.4GB/s |
| Storage | Supports external NVMe | |
| Power | 10W ~ 20W | 10W ~ 25W |
| PCIe* | 1 x4 + 3 x1 (PCIe Gen4, Root Port, & Endpoint) | |
| USB* | 3x USB 3.2 2.0 (10 Gbps) 3x USB 2.0 |
|
| CSI Camera | Up to 4 cameras (8 via virtual channels**) 8 lanes MIPI CSI-2 D-PHY 1.2 (up to 20 Gbps) |
|
| Video encode | 1x 4K60 (H.265) | 3x 4K30 (H.265) 6x 1080p60 (H.265) | 12x 1080p30 (H.265) |
|
| Video decode | 1x 8K30 (H.265) | 2x 4K60 (H.265) | 4x 4K30 (H.265) 9x 1080p60 (H.265) | 18x 1080p30 (H.265) |
|
| Display | 1x 8K30 multi-mode DP 1.4a (+MST)/eDP 1.4a/HDMI 2.1 | |
| Other | 3x UART, 2x SPI, 2x I2S, 4x I2C, 1x CAN, DMIC & DSPK, PWM, GPIO | |
| Networking | 1x GbE | |
| Dimensions | 69.6 mm x 45 mm 260-pin SO-DIMM connector |
Package Includes:
