Vero Board Single Side 8x12cm
Out of stock
This product is out of stock. Are you interested about this product?
The Vero Board Single Side is a high-quality prototyping board designed to streamline your electronics projects. Measuring 8x12 cm, this board offers ample space for creating and testing your circuits with ease. Its single-sided design features a grid of perforated copper pads, which makes it ideal for various applications, from simple breadboard experiments to more complex electronic assemblies.
Key Features:
- Dimensions: 8x12 cm, providing a compact yet spacious area for prototyping.
- Material: Made from durable, high-quality fiberglass with a single layer of copper plating.
- Copper Pads: The board is pre-coppered on one side with a grid layout, allowing for versatile circuit design and soldering.
- Perforation Grid: The perforated grid pattern helps in easy placement and alignment of components, simplifying the soldering process.
- Compatibility: Suitable for use with standard electronic components, including resistors, capacitors, and integrated circuits.
Instructions for Use:
-
Planning Your Circuit:
- Sketch your circuit design on paper or use circuit design software.
- Identify the locations for your components and their connections.
-
Component Placement:
- Insert the electronic components into the perforations of the Vero Board according to your circuit design.
- Ensure that the component leads align with the copper pads.
-
Soldering:
- Heat your soldering iron to the recommended temperature (typically around 350°C or 662°F).
- Solder each connection by heating the copper pad and component lead, then applying solder. Allow the solder to cool and solidify.
-
Testing:
- After soldering, inspect your connections to ensure they are secure and free from solder bridges.
- Use a multimeter to test the continuity and functionality of your circuit.
-
Cutting and Shaping:
- If necessary, you can cut the Vero Board to size using a saw or scissors designed for cutting PCB material.
- Be cautious to avoid damaging the copper pads during cutting.
Additional Tips:
- For a cleaner project, you can use a soldering iron with a fine tip and flux to ensure precision in soldering.
- Make sure to follow safety precautions while working with soldering equipment, including using proper ventilation and protective eyewear.
Applications:
- Ideal for prototyping and testing electronic circuits.
- Perfect for hobbyists, students, and engineers working on DIY electronics projects.
Package Contents:
- 1 x Vero Board Single Side (8x12 cm)
